Functions and Features
Midea's M-Thermal Arctic Series heat pump with environmentally friendly R32 refrigerant can be combined with any heating, cooling, and domestic hot water production system.
A built-in water tank is included for installation flexibility and Wi-Fi for control from anywhere.
Suitable for applications with water temperature up to 65 °C.
Technical characteristics
|
Type |
M thermal A Series Mono |
|
||
|
Power Supply (Ph-V-Hz) |
220-240/1/50 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 30 35°C) |
4.20~15.9 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 40 45°C) |
4.30~16.0 |
|||
|
Heating Capacity (kW, Evaporator air in 7°C, 85% R.H., Condenser water in out 47 55°C) |
4.40~16.0 |
|||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 23 18°C) |
4.50~14.9 |
|||
|
Cooling Capacity (kW, Condenser air in 35°C. Evaporator water in out 12 7°C) |
4.70~14.0 |
|||
|
Net dimensions (W×H×D)(mm) |
(1295×792×429)~(1385×945×526) |
|||
|
Packed dimensions (W×H×D)(mm) |
(1375×965×475)~(1465×1120×560) |
|||
|
Net weight(kg) |
95~133 |
|||
|
Gross weight(kg) |
110~161 |
|||
|
Ambient temp.operation range(Cooling)(℃) |
-5~43 |
|||
|
Ambient temp.operation range(Heating)(℃) |
-25~35 |
|||
|
Ambient temp.operation range(DHW)(℃) |
-25~43 |
|||
|
Water outlet temp. range(Cooling)(℃) |
5~25 |
|||
|
Water outlet temp. range(Heating)(℃) |
25~65 |
|||
|
Water outlet temp. range(DHW)(℃) |
40~60 |
|||
 |
